H2475-01
Terminals - PC Pin, Single Post Connectors
- Manufacturer No:
- H2475-01
- Manufacture:
- Harwin Inc.
- Datasheet:
- H2475-01
- Description:
- CONN PC PIN CIRC 0.020DIA TIN
In Stock
3998 pcs On sales
$0.37
Product Parameter
- Part Status
- Active
- Length - Below Flange
- 0.118" (3.00mm)
- Termination
- Swage, Barbed
- Material - Insulation
- -
- Mounting Type
- Through Hole
- Mounting Hole Diameter
- 0.030" ~ 0.033" (0.76mm ~ 0.84mm)
- Terminal Type
- PC Pin
- Pin Size - Above Flange
- 0.020" (0.51mm) Dia
- Contact Finish
- Tin
- Pin Size - Below Flange
- 0.030" (0.76mm) Dia
- Terminal Style
- Double End
- Contact Finish Thickness
- -
- Board Thickness
- 0.063" (1.60mm)
- Flange Diameter
- 0.050" (1.27mm)
- Contact Material
- Brass
- Series
- -
- Insulation Color
- -
- Packaging
- Bulk
- Length - Overall
- 0.287" (7.29mm)
- Insulation
- Non-Insulated
- Length - Above Flange
- -
