46.52.8.120.0054
Power Relays, Over 2 Amps
- Manufacturer No:
- 46.52.8.120.0054
- Manufacture:
- Finder Relays, Inc.
- Datasheet:
- 46.52.8.120.0054
- Description:
- RELAY DPDT 8A 120V
In Stock
50 pcs On sales
$12.49
Product Parameter
- Packaging
- Bulk
- Contact Material
- Silver Nickel (AgNi)
- Relay Type
- General Purpose
- Switching Voltage
- 440VAC - Max
- Part Status
- Active
- Termination Style
- Plug In, Quick Connect - 0.110" (2.8mm)
- Seal Rating
- -
- Must Operate Voltage
- 96 VAC
- Coil Current
- 8.4mA
- Must Release Voltage
- 24 VAC
- Coil Voltage
- 120VAC
- Operating Temperature
- -40°C ~ 70°C
- Contact Form
- DPDT (2 Form C)
- Contact Rating (Current)
- 8A
- Operate Time
- 10ms
- Release Time
- 3ms
- Series
- 46
- Mounting Type
- Socketable
- Features
- Lighted Indicator, Mechanical Indicator, Test Button
- Coil Insulation
- -
- Coil Type
- Non Latching
- Coil Resistance
- 9 kOhms
