E3G0603S-3
Rotary Switches
- Manufacturer No:
- E3G0603S-3
- Manufacture:
- Electroswitch
- Datasheet:
- E3G0603S-3
- Description:
- SWITCH ROTARY 3POS 500MA 115V
In Stock
0 pcs On sales
$60.78
Product Parameter
- Actuator Type
- Round (6.35mm Dia)
- Number of Positions
- 3
- Mounting Type
- Panel Mount
- Voltage Rating - AC
- 115V
- Angle of Throw
- 30°
- Voltage Rating - DC
- 28V
- Contact Finish
- Silver
- Current Rating (Amps)
- 500mA (AC), 1.5A (DC)
- Contact Timing
- Shorting (MBB)
- Panel Cutout Dimensions
- Circular - 9.78mm Dia
- Actuator Length
- 47.63mm
- Number of Poles per Deck
- 3
- Number of Decks
- 2
- Operating Force
- -
- Series
- E3
- Circuit per Deck
- 3P3T
- Features
- Spring Return
- Contact Material
- Brass
- Index Stops
- Fixed
- Termination Style
- Solder Lug
- Part Status
- Active
- Depth Behind Panel
- 11.96mm
