DV5214/2N
DC Brushless Fans (BLDC)
- Manufacturer No:
- DV5214/2N
- Manufacture:
- ebm-papst Inc.
- Datasheet:
- DV5214/2N
- Description:
- FAN TUBEAXIAL
In Stock
20 pcs On sales
$107.63
Product Parameter
- Approvals
- -
- Ingress Protection
- IP54 - Dust Protected, Water Resistant
- Part Status
- Active
- Current Rating (Amps)
- -
- Termination
- 3 Wire Leads
- Operating Temperature
- -4 ~ 149°F (-20 ~ 65°C)
- Bearing Type
- Ball
- Power (Watts)
- 20.40W
- RPM
- 5000 RPM
- Voltage Range
- 16 ~ 30VDC
- Noise
- 56.0 dB(A)
- Static Pressure
- -
- Width
- 38.00mm
- Voltage - Rated
- 24VDC
- Series
- DV5200
- Lifetime @ Temp.
- 70000 Hrs @ 40°C
- Air Flow
- 159.0 CFM (4.45m³/min)
- Material - Blade
- Polyamide (PA), Nylon, Fiberglass Reinforced
- Fan Type
- Tubeaxial
- Material - Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Features
- Speed Sensor (Tach)
- Size / Dimension
- Square - 127mm L x 127mm H
