4318/17T
DC Brushless Fans (BLDC)
- Manufacturer No:
- 4318/17T
- Manufacture:
- ebm-papst Inc.
- Datasheet:
- 4318/17T
- Description:
- FAN AXIAL 119X32MM 48VDC WIRE
In Stock
3 pcs On sales
$69.17
Product Parameter
- RPM
- 2800 RPM
- Power (Watts)
- 5.30W
- Noise
- 45.0 dB(A)
- Voltage Range
- 36 ~ 74.9VDC
- Width
- 32.00mm
- Static Pressure
- 0.313 in H2O (78.0 Pa)
- Series
- 4300
- Voltage - Rated
- 48VDC
- Weight
- -
- Lifetime @ Temp.
- Varies Based on Temperature
- Air Flow
- 100.1 CFM (2.80m³/min)
- Material - Blade
- Polyamide (PA), Nylon, Fiberglass Reinforced
- Fan Type
- Tubeaxial
- Material - Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Features
- -
- Size / Dimension
- Square - 119mm L x 119mm H
- Approvals
- CCC, CE, CSA, UL, VDE
- Ingress Protection
- -
- Part Status
- Active
- Current Rating (Amps)
- 0.110A
- Termination
- 4 Wire Leads
- Operating Temperature
- -4 ~ 151°F (-20 ~ 66°C)
- Bearing Type
- Ball
