TLE1105AF160Q
Tactile Switches
- Manufacturer No:
- TLE1105AF160Q
- Manufacture:
- E-Switch
- Datasheet:
- TLE1105AF160Q
- Description:
- SWITCH TACTILE SPST-NO 0.05A 12V
In Stock
4946 pcs On sales
$0.29
Product Parameter
- Operating Force
- 160gf
- Series
- TL1105
- Switch Function
- Off-Mom
- Circuit
- SPST-NO
- Actuator Material
- Polyamide (PA), Nylon
- Outline
- 6.00mm x 6.00mm
- Termination Style
- PC Pin
- Features
- Grounding Pin
- Ingress Protection
- -
- Packaging
- Bulk
- Actuator Orientation
- Top Actuated
- Part Status
- Active
- Operating Temperature
- -20°C ~ 70°C
- Illumination
- Non-Illuminated
- Contact Rating @ Voltage
- 0.05A @ 12VDC
- Actuator Type
- Standard
- Illumination Type, Color
- -
- Mounting Type
- Through Hole
- Actuator Length, Right Angle
- -
- Switch Travel
- 0.25mm
- Illumination Voltage (Nominal)
- -
- Mechanical Life
- 100,000 Cycles
- Actuator Height off PCB, Vertical
- 5.00mm
