THA0412BN
DC Brushless Fans (BLDC)
- Manufacturer No:
- THA0412BN
- Manufacture:
- Delta Electronics
- Datasheet:
- THA0412BN
- Description:
- FAN AXIAL 40X28MM 12VDC WIRE
In Stock
7166 pcs On sales
$21.08
Product Parameter
- Features
- PWM Control, Speed Sensor (Tach)
- Size / Dimension
- Square - 40mm L x 40mm H
- Approvals
- CE, cURus, TUV
- Ingress Protection
- -
- Part Status
- Active
- Current Rating (Amps)
- 0.890A
- Termination
- 4 Wire Leads
- Operating Temperature
- 14 ~ 158°F (-10 ~ 70°C)
- Bearing Type
- Ball
- RPM
- 19000 RPM
- Power (Watts)
- 10.70W
- Noise
- 59.0 dB(A)
- Voltage Range
- 7 ~ 13.2VDC
- Width
- 28.00mm
- Static Pressure
- 2.400 in H2O (597.8 Pa)
- Series
- THA
- Voltage - Rated
- 12VDC
- Weight
- 0.101 lb (45.81 g)
- Lifetime @ Temp.
- 70000 Hrs @ 40°C
- Air Flow
- 29.5 CFM (0.826m³/min)
- Material - Blade
- Plastic
- Fan Type
- Tubeaxial
- Material - Frame
- Aluminum
