IPM24S0C0R03FA
DC DC Converters
- Manufacturer No:
- IPM24S0C0R03FA
- Manufacture:
- Delta Electronics
- Package:
- 5-SIP Module
- Datasheet:
- IPM24S0C0R03FA
- Description:
- DC DC CONVERTER 8-15V 45W
In Stock
0 pcs On sales
$0
Product Parameter
- Series
- Delphi IPM24S
- Voltage - Output 1
- 8 ~ 15V
- Features
- Remote On/Off, OCP, SCP, UVLO
- Voltage - Output 2
- -
- Packaging
- Tube
- Voltage - Output 3
- -
- Efficiency
- 95%
- Operating Temperature
- -40°C ~ 75°C
- Part Status
- Obsolete
- Voltage - Input (Max)
- 36V
- Applications
- ITE (Commercial)
- Voltage - Input (Min)
- 20V
- Mounting Type
- Through Hole
- Current - Output (Max)
- 3A, 3A
- Power (Watts)
- 45W
- Supplier Device Package
- -
- Package / Case
- 5-SIP Module
- Control Features
- Enable, Active High
- Size / Dimension
- 0.70" L x 0.31" W x 0.64" H (17.8mm x 7.8mm x 16.3mm)
- Type
- Non-Isolated PoL Module
- Number of Outputs
- 2
Company Profile
Atlaschip is a globally authorized distributor of semiconductors and electronic components ,IC ,COF/ TAB ,Opencell for over 600 industry-leading manufacturer brands. a key resource for design engineers. We are guides innovation forward for the global leading technology manufacturers and service providers.
IPM24S0C0R03FA Relevant information
IPM24S0A0R03FA
DC DC CONVERTER 1.2-2.5V 7.5W
IPM24S0A0S03FA
DC DC CONVERTER 1.2-2.5V 7.5W
IPM24S0B0R03FA
DC DC CONVERTER 3.3-6.5V 45W
IPM24S0B0S03FA
DC DC CONVERTER 3.3-6.5V 20W
IPM24S0C0R03FA
DC DC CONVERTER 8-15V 45W
IPM24S0C0S03FA
DC DC CONVERTER 8-15V 45W
