GFM0412SS-BL4F
DC Brushless Fans (BLDC)
- Manufacturer No:
- GFM0412SS-BL4F
- Manufacture:
- Delta Electronics
- Datasheet:
- GFM0412SS-BL4F
- Description:
- FAN AXIAL DUAL 40X56MM 12VDC
In Stock
142 pcs On sales
$38.27
Product Parameter
- Series
- -
- Voltage - Rated
- 12VDC
- Weight
- 0.183 lb (83.01 g)
- Lifetime @ Temp.
- -
- Air Flow
- 27.1 CFM (0.759m³/min)
- Material - Blade
- Plastic
- Fan Type
- Tubeaxial (Dual)
- Material - Frame
- Plastic
- Features
- PWM Control, Speed Sensor (Tach)
- Size / Dimension
- Square - 40mm L x 40mm H
- Approvals
- -
- Ingress Protection
- -
- Part Status
- Active
- Current Rating (Amps)
- 0.800A
- Termination
- 4 Wire Leads per Fan
- Operating Temperature
- 14 ~ 158°F (-10 ~ 70°C)
- Bearing Type
- Ball
- RPM
- 17200 Front, 14000 Rear
- Power (Watts)
- 9.60W
- Noise
- 61.5 dB(A)
- Voltage Range
- 10.8 ~ 12.6VDC
- Width
- 56.00mm
- Static Pressure
- 2.230 in H2O (555.5 Pa)
