FHB1248DHE-TXKW
DC Brushless Fans (BLDC)
- Manufacturer No:
- FHB1248DHE-TXKW
- Manufacture:
- Delta Electronics
- Datasheet:
- FHB1248DHE-TXKW
- Description:
- FAN AXIAL 120X38MM 48VDC WIRE
In Stock
0 pcs On sales
$0
Product Parameter
- Width
- 38.00mm
- Static Pressure
- 1.502 in H2O (374.1 Pa)
- Series
- FHB
- Voltage - Rated
- 48VDC
- Weight
- 1.102 lb (500.0 g)
- Lifetime @ Temp.
- 100000 Hrs @ 40°C
- Air Flow
- 245.8 CFM (6.88m³/min)
- Material - Blade
- Plastic
- Fan Type
- Tubeaxial
- Material - Frame
- Aluminum
- Features
- PWM Control, Speed Sensor (Tach)
- Size / Dimension
- Square - 120mm L x 120mm H
- Approvals
- CE, CSA, UL, VDE
- Ingress Protection
- -
- Part Status
- Obsolete
- Current Rating (Amps)
- 1.32A
- Termination
- 4 Wire Leads
- Operating Temperature
- -40 ~ 176°F (-40 ~ 80°C)
- Bearing Type
- Ball
- RPM
- 5800 RPM
- Power (Watts)
- 63.4W
- Noise
- 71.5 dB(A)
- Voltage Range
- 32 ~ 80VDC
