82930002
Stepper Motors
- Manufacturer No:
- 82930002
- Manufacture:
- Crouzet
- Datasheet:
- 82930002
- Description:
- STEPPER MOTOR PM BIPOLAR 10.4V
In Stock
0 pcs On sales
$42.61
Product Parameter
- Type
- Permanent Magnet
- Diameter - Shaft
- 0.157" (4.00mm)
- Series
- 82930
- Size / Dimension
- Round - 2.280" Dia (57.80mm)
- Weight
- 0.75 lb (340.19 g)
- Termination Style
- Wire Leads
- Accuracy
- -
- Steps per Revolution
- 48
- Features
- Round Shaft
- Current Rating (Amps)
- 480mA
- Approvals
- -
- Mounting Hole Spacing
- 2.630" (66.68mm)
- Coil Type
- Bipolar
- Operating Temperature
- -
- Step Angle
- 7.5°
- Length - Shaft and Bearing
- 0.630" (16.00mm)
- Part Status
- Active
- Torque - Holding (oz-in / mNm)
- 25.5 / 180
- Rotor Inertia
- 84gcm²
- Coil Resistance
- 22.3 Ohms
- Voltage - Rated
- 10.4VDC
