400F0-25-1-00

D-Sub Connectors

Manufacturer No:: 400F0-25-1-00
Manufacture:: CnC Tech
Datasheet:: 400F0-25-1-00
Description:: CONN D-SUB RCPT 25POS IDC

In Stock

919 pcs On sales

$2.8

Product Parameter

Features: Feed Through

Voltage Rating: 250V

Shell Size, Connector Layout: 3 (DB, B)

Packaging: Bulk

Backset Spacing: -

Wire Gauge: -

Connector Style: D-Sub

Part Status: Active

Contact Material: Brass

Termination: IDC, Ribbon Cable

Ingress Protection: -

Contact Form: -

Dielectric Material: Polybutylene Terephthalate (PBT), Glass Filled

Contact Type: Signal

Number of Positions: 25

Mounting Type: Free Hanging (In-Line)

Current Rating (Amps): 1A

Connector Type: Receptacle, Female Sockets

Operating Temperature: -40°C ~ 105°C

Contact Finish: Gold

Shell Material, Finish: Steel, Nickel Plated

Color: -

Flange Feature: Mating Side, Female Screwlock (4-40)

Contact Finish Thickness: -

Series: -

Number of Rows: 2

Material Flammability Rating: UL94 V-0
