2N3501
Transistors - Bipolar (BJT) - Single
- Manufacturer No:
- 2N3501
- Manufacture:
- Central Semiconductor Corp
- Package:
- TO-205AD, TO-39-3 Metal Can
- Datasheet:
- 2N3501
- Description:
- TRANS NPN 150V 0.3A TO-39
In Stock
96 pcs On sales
$7.83
Product Parameter
- Part Status
- Active
- Voltage - Collector Emitter Breakdown (Max)
- 150V
- Power - Max
- 1W
- Mounting Type
- Through Hole
- Package / Case
- TO-205AD, TO-39-3 Metal Can
- Transistor Type
- NPN
- Operating Temperature
- -65°C ~ 200°C (TJ)
- Frequency - Transition
- 150MHz
- Supplier Device Package
- TO-39
- Vce Saturation (Max) @ Ib, Ic
- 400mV @ 15mA, 150mA
- Current - Collector (Ic) (Max)
- 300mA
- Series
- -
- Current - Collector Cutoff (Max)
- 50nA (ICBO)
- Packaging
- Bulk
- DC Current Gain (hFE) (Min) @ Ic, Vce
- 100 @ 150mA, 10V
