OS102011MS2QN1
Slide Switches
- Manufacturer No:
- OS102011MS2QN1
- Manufacture:
- C&K
- Datasheet:
- OS102011MS2QN1
- Description:
- SWITCH SLIDE SPDT 100MA 12V
In Stock
34194 pcs On sales
$0.43
Product Parameter
- Circuit
- SPDT
- Operating Force
- -
- Features
- Epoxy Sealed Terminals
- Switch Function
- On-On
- Packaging
- Bulk
- Contact Material
- Copper Alloy
- Part Status
- Active
- Actuator Material
- Polyoxymethylene (Acetal) (POM)
- Actuator Type
- Standard
- Termination Style
- PC Pin
- Mounting Type
- Through Hole
- Voltage Rating - DC
- 12V
- Switch Travel
- 2.00mm
- Current Rating (Amps)
- 100mA (DC)
- Contact Finish
- Silver
- Operating Temperature
- -30°C ~ 70°C
- Contact Timing
- Non-Shorting (BBM)
- Actuator Length
- 4.00mm
- Electrical Life
- 10,000 Cycles
- Series
- OS
- Mechanical Life
- 10,000 Cycles
