9064 0101000
Coaxial Cables (RF)
- Manufacturer No:
- 9064 0101000
- Manufacture:
- Belden Inc.
- Datasheet:
- 9064 0101000
- Description:
- COAX 75 OHM RG11 14AWG
In Stock
0 pcs On sales
$419.22
Product Parameter
- Length
- 1000.0' (304.80m)
- Conductor Material
- Steel, Copper Coated
- Series
- -
- Dielectric Diameter
- 0.280" (7.11mm)
- Impedance
- 75 Ohms
- Dielectric Material
- Foam Polyethylene (FPE)
- Cable Type
- Coaxial
- Operating Temperature
- -40°C ~ 80°C
- Wire Gauge
- 14 AWG
- Jacket (Insulation) Diameter
- 0.393" (9.98mm)
- Cable Group
- RG-11
- Jacket (Insulation) Material
- Poly-Vinyl Chloride (PVC)
- Part Status
- Active
- VoP, Velocity of Propagation
- 83
- Shield Type
- Foil, Braid
- Jacket Color
- Black
- Shield Coverage
- 100%, 77%
- Shield Material
- Aluminum
- Conductor Strand
- Solid
