3092A 010500
Coaxial Cables (RF)
- Manufacturer No:
- 3092A 010500
- Manufacture:
- Belden Inc.
- Datasheet:
- 3092A 010500
- Description:
- CABLE COAXIAL 18AWG 75 OHM
In Stock
2 pcs On sales
$641.74
Product Parameter
- Length
- 500.0' (152.40m)
- Conductor Strand
- Solid
- Series
- ControlNet™
- Conductor Material
- Steel, Copper Coated
- Features
- -
- Dielectric Diameter
- 0.180" (4.57mm)
- Impedance
- 75 Ohms
- Dielectric Material
- Foam Polyethylene (FPE)
- Cable Type
- Coaxial
- Operating Temperature
- -30°C ~ 75°C
- Wire Gauge
- 18 AWG
- Jacket (Insulation) Diameter
- 0.298" (7.57mm)
- Cable Group
- RG-6
- Jacket (Insulation) Material
- Poly-Vinyl Chloride (PVC)
- Part Status
- Active
- VoP, Velocity of Propagation
- 82
- Shield Type
- Foil, Double Braid
- Jacket Color
- Black
- Shield Coverage
- 100%, 60%, 40%
- Usage
- -
- Shield Material
- Aluminum
