0ZSC0600FF1E

PTC Resettable Fuses

Manufacturer No:: 0ZSC0600FF1E
Manufacture:: Bel Fuse, Inc.
Package:: Strap
Datasheet:: 0ZSC0600FF1E
Description:: PTC RESET FUSE 20V 6.0A STRAP

In Stock

2999 pcs On sales

$0.81

Product Parameter

Part Status: Active

Current - Hold (Ih) (Max): 6A

Lead Spacing: -

Resistance - Initial (Ri) (Min): 7 mOhms

Time to Trip: 5s

Resistance - Post Trip (R1) (Max): 19 mOhms

Current - Max: 100A

Mounting Type: User Defined

Voltage - Max: 20V

Package / Case: Strap

Type: Polymeric

Thickness (Max): 0.039" (1.00mm)

Series: 0ZSC

Size / Dimension: 0.984" L x 0.559" W (25.00mm x 14.20mm)

Ratings: -

Current - Trip (It): 11.7A

Approvals: cURus, TUV

Height - Seated (Max): -

Packaging: -

Operating Temperature: -40°C ~ 85°C
