ECL15US03-E
AC DC Converters
- Manufacturer No:
- ECL15US03-E
- Manufacture:
- XP Power
- Package:
- 4-DIP Module
- Datasheet:
- ECL15US03-E
- Description:
- AC/DC CONVERTER 3.3V 10W
In Stock
0 pcs On sales
$34.97
Product Parameter
- Power (Watts)
- 15W
- Current - Output (Max)
- 3A
- Package / Case
- 4-DIP Module
- Line Regulation
- ±0.5%
- Type
- Enclosed
- Load Regulation
- ±1%
- Series
- ECL (15W)
- Voltage - Input
- 85 ~ 264 VAC
- Weight
- 0.199 lb (90.26 g)
- Size / Dimension
- 2.56" L x 1.31" W x 0.96" H (65.0mm x 33.3mm x 24.4mm)
- Features
- OCP, OVP, SCP
- Number of Outputs
- 1
- Approvals
- CSA, cUL, EN, IEC, UL
- Voltage - Output 1
- 3.3V
- Efficiency
- 75%
- Voltage - Output 2
- -
- Part Status
- Active
- Voltage - Output 3
- -
- Applications
- ITE (Commercial)
- Voltage - Output 4
- -
- Mounting Type
- Through Hole
- Operating Temperature
- -20°C ~ 70°C (With Derating)
