694106301002

Barrel - Power Connectors

Manufacturer No:: 694106301002
Manufacture:: Wurth Electronics Inc.
Datasheet:: 694106301002
Description:: CONN PWR JACK 2.1X5.5MM SOLDER

In Stock

7310 pcs On sales

$0.96

Product Parameter

Part Status: Active

Internal Switch(s): Single Switch, Normally Closed

Termination: Solder Eyelet(s)

Dielectric Material: Polyamide (PA66), Nylon 6/6

Thread Size: -

Mating Length/Depth: 0.354" (9.00mm)

Body Material: -

Current Rating (Amps): 5A

Mounting Type: Through Hole, Right Angle

Operating Temperature: -40°C ~ 85°C

Gender: Male

Connector Type: Jack

Contact Material - Plating: Tin

Series: WR-DC

Actual Diameter: 0.081" (2.05mm ID), 0.252" (6.40mm OD)

Material Flammability Rating: UL94 V-0

Features: -

Voltage - Rated: 24VDC

Number of Positions/Contacts: 2 Conductors, 3 Contacts

Includes: -

Contact Material: Copper Alloy

Industry Recognized Mating Diameter: 2.10mm ID (0.083"), 5.50mm OD (0.217")

Packaging: Bulk

Insulation Color: -

Shielding: Unshielded

Mounting Feature: -

Body Color: Black

Ingress Protection: -
