ISO5452DWR
Isolators - Gate Drivers
- Manufacturer No:
- ISO5452DWR
- Manufacture:
- Texas Instruments
- Package:
- 16-SOIC (0.295", 7.50mm Width)
- Datasheet:
- ISO5452DWR
- Description:
- DGTL ISO 5.7KV GATE DRVR 16SOIC
In Stock
2798 pcs On sales
$0
Product Parameter
- Packaging
- Digi-Reel®
- Current - Output High, Low
- 1.5A, 3.4A
- Technology
- Capacitive Coupling
- Pulse Width Distortion (Max)
- -
- Part Status
- Active
- Voltage - Forward (Vf) (Typ)
- -
- Mounting Type
- Surface Mount
- Propagation Delay tpLH / tpHL (Max)
- 110ns, 110ns
- Package / Case
- 16-SOIC (0.295", 7.50mm Width)
- Common Mode Transient Immunity (Min)
- 50kV/µs
- Number of Channels
- 1
- Voltage - Isolation
- 5700Vrms
- Current - Peak Output
- 2.7A, 5.5A
- Operating Temperature
- -40°C ~ 125°C
- Rise / Fall Time (Typ)
- 18ns, 20ns
- Series
- -
- Supplier Device Package
- 16-SOIC
- Approvals
- CQC, CSA, UR, VDE
- Voltage - Output Supply
- 15V ~ 30V
