S87R5D2B1D1-12
Power Relays, Over 2 Amps
- Manufacturer No:
- S87R5D2B1D1-12
- Manufacture:
- TE Connectivity Potter & Brumfield Relays
- Datasheet:
- S87R5D2B1D1-12
- Description:
- RELAY GEN PURPOSE SPDT 20A 12V
In Stock
0 pcs On sales
$33.93
Product Parameter
- Part Status
- Active
- Must Release Voltage
- -
- Seal Rating
- -
- Operating Temperature
- -10°C ~ 65°C
- Coil Current
- 240mA
- Contact Rating (Current)
- 20A
- Coil Voltage
- 12VDC
- Contact Form
- SPDT (1 Form C)
- Mounting Type
- Chassis Mount
- Coil Insulation
- Class B
- Series
- S87R
- Coil Resistance
- 50 Ohms
- Features
- -
- Contact Material
- Silver Cadmium Oxide (AgCdO)
- Coil Type
- Non Latching
- Switching Voltage
- 277VAC - Max
- Packaging
- Tray
- Termination Style
- Quick Connect - 0.250" (6.3mm)
- Relay Type
- General Purpose
- Must Operate Voltage
- 9 VDC
