RTE25024
Power Relays, Over 2 Amps
- Manufacturer No:
- RTE25024
- Manufacture:
- TE Connectivity Potter & Brumfield Relays
- Datasheet:
- RTE25024
- Description:
- RELAY GEN PURPOSE DPDT 8A 24V
In Stock
1331 pcs On sales
$8.86
Product Parameter
- Seal Rating
- Sealed - Fully
- Must Operate Voltage
- 16.8 VDC
- Coil Current
- 16.7mA
- Must Release Voltage
- 2.4 VDC
- Coil Voltage
- 24VDC
- Operating Temperature
- -40°C ~ 85°C
- Contact Form
- DPDT (2 Form C)
- Contact Rating (Current)
- 8A
- Operate Time
- 8ms
- Release Time
- 6ms
- Series
- RT2, SCHRACK
- Mounting Type
- Through Hole
- Features
- -
- Coil Insulation
- Class F
- Coil Type
- Non Latching
- Coil Resistance
- 1.44 kOhms
- Packaging
- Tube
- Contact Material
- Silver Nickel (AgNi), Gold (Au)
- Relay Type
- General Purpose
- Switching Voltage
- 400VAC - Max
- Part Status
- Active
- Termination Style
- PC Pin
