OJE-SH-124LMH,000
Power Relays, Over 2 Amps
- Manufacturer No:
- OJE-SH-124LMH,000
- Manufacture:
- TE Connectivity Potter & Brumfield Relays
- Datasheet:
- OJE-SH-124LMH,000
- Description:
- RELAY GEN PURPOSE SPST 8A 24V
In Stock
530 pcs On sales
$1.66
Product Parameter
- Packaging
- Bulk
- Contact Material
- Silver Cadmium Oxide (AgCdO)
- Relay Type
- General Purpose
- Switching Voltage
- 277VAC, 30VDC - Max
- Part Status
- Active
- Termination Style
- PC Pin
- Seal Rating
- Sealed - Fully
- Must Operate Voltage
- 18 VDC
- Coil Current
- 8.6mA
- Must Release Voltage
- 1.2 VDC
- Coil Voltage
- 24VDC
- Operating Temperature
- -30°C ~ 70°C
- Contact Form
- SPST-NO (1 Form A)
- Contact Rating (Current)
- 8A
- Operate Time
- 15ms
- Release Time
- 4ms
- Series
- OJE, OEG
- Mounting Type
- Through Hole
- Features
- -
- Coil Insulation
- -
- Coil Type
- Non Latching
- Coil Resistance
- 2.88 kOhms
