5645994-1
Terminals - PC Pin Receptacles, Socket Connectors
- Manufacturer No:
- 5645994-1
- Manufacture:
- TE Connectivity AMP Connectors
- Datasheet:
- 5645994-1
- Description:
- CONN PIN RCPT .026-.033 SOLDER
In Stock
19975 pcs On sales
$0
Product Parameter
- Flange Diameter
- 0.072" (1.83mm)
- Insertion Force
- -
- Series
- 3
- Contact Material
- Beryllium Copper
- Features
- -
- Length - Overall
- 0.257" (6.53mm)
- Packaging
- Digi-Reel®
- Pin Hole Diameter
- -
- Tail Type
- No Tail
- Accepts Pin Diameter
- 0.026" ~ 0.033" (0.66mm ~ 0.84mm)
- Part Status
- Active
- Operating Temperature
- -65°C ~ 125°C
- Termination
- Solder
- Mounting Hole Diameter
- 0.062" (1.57mm)
- Socket Depth
- -
- Accepts Square Pin Size
- -
- Tail Diameter
- -
- Contact Finish Thickness
- 30.0µin (0.76µm)
- Contact Finish
- Gold
- Board Thickness
- 0.031" ~ 0.125" (0.79mm ~ 3.18mm)
