52956-1
Terminals - Spade Connectors
- Manufacturer No:
- 52956-1
- Manufacture:
- TE Connectivity AMP Connectors
- Datasheet:
- 52956-1
- Description:
- CONN SPADE TERM 14-16AWG #8 BLU
In Stock
3114 pcs On sales
$0.56
Product Parameter
- Contact Finish
- Tin
- Color
- Blue
- Contact Material
- Brass
- Series
- Plasti-Grip
- Length - Overall
- 0.872" (22.15mm)
- Features
- Serrated Termination
- Insulation Diameter
- 0.118" ~ 0.193" (3.00mm ~ 4.90mm)
- Packaging
- Cut Tape (CT)
- Width - Outer Edges
- 0.375" (9.53mm)
- Insulation
- Insulated
- Length - Termination
- 0.416" (10.57mm)
- Wire Gauge
- 14-16 AWG
- Material - Insulation
- Poly-Vinyl Chloride (PVC)
- Part Status
- Discontinued at Digi-Key
- Tongue Inside Opening
- 0.164" (4.17mm)
- Termination
- Crimp
- Length - Ring Center to Termination
- 0.281" (7.14mm)
- Mounting Type
- Free Hanging (In-Line)
- Stud/Tab Size
- 8 Stud
- Terminal Type
- Spring, Snap
