34166
Terminals - Spade Connectors
- Manufacturer No:
- 34166
- Manufacture:
- TE Connectivity AMP Connectors
- Datasheet:
- 34166
- Description:
- CONN SPADE TERM 14-16AWG #8 BLU
In Stock
5190 pcs On sales
$0.42
Product Parameter
- Part Status
- Active
- Tongue Inside Opening
- 0.171" (4.34mm)
- Termination
- Crimp
- Length - Ring Center to Termination
- 0.312" (7.92mm)
- Mounting Type
- Free Hanging (In-Line)
- Stud/Tab Size
- 8 Stud
- Terminal Type
- Standard
- Contact Finish
- -
- Color
- Blue
- Contact Material
- Copper
- Series
- Plasti-Grip
- Length - Overall
- 0.920" (23.37mm)
- Features
- Serrated Termination
- Insulation Diameter
- 0.118" ~ 0.193" (3.00mm ~ 4.90mm)
- Packaging
- Bulk
- Width - Outer Edges
- 0.385" (9.78mm)
- Insulation
- Insulated
- Length - Termination
- 0.416" (10.57mm)
- Wire Gauge
- 14-16 AWG
- Material - Insulation
- Poly-Vinyl Chloride (PVC)
