31398

Terminals - Ring Connectors

Manufacturer No:: 31398
Manufacture:: TE Connectivity AMP Connectors
Datasheet:: 31398
Description:: CONN RING CIRC 16-22AWG #10

In Stock

0 pcs On sales

$0.68

Product Parameter

Part Status: Active

Termination: Crimp

Mounting Type: Free Hanging (In-Line)

Stud/Tab Size: 10 Stud

Terminal Type: Circular

Color: -

Contact Finish: Tin

Series: Diamond Grip

Contact Material: Copper

Features: Serrated Termination

Length - Overall: 0.728" (18.49mm)

Packaging: Bulk

Insulation Diameter: 0.105" ~ 0.140" (2.67mm ~ 3.56mm)

Thickness: 0.031" (0.79mm)

Width - Outer Edges: 0.281" (7.14mm)

Insulation: Non-Insulated

Material - Insulation: -

Wire Gauge: 16-22 AWG
