B07D992BE2-0132
Power Relays, Over 2 Amps
- Manufacturer No:
- B07D992BE2-0132
- Manufacture:
- TE Connectivity Aerospace Defense and Marine
- Datasheet:
- B07D992BE2-0132
- Description:
- RELAY GEN PURPOSE DPDT 10A 120V
In Stock
0 pcs On sales
$203.61
Product Parameter
- Coil Current
- 15.8mA
- Must Release Voltage
- 7.7 VDC
- Coil Voltage
- 120VDC
- Operating Temperature
- -65°C ~ 125°C
- Contact Form
- DPDT (2 Form C)
- Contact Rating (Current)
- 10A
- Operate Time
- 15ms
- Release Time
- 15ms
- Series
- Military, MIL-R-5757/23, 07, CII
- Mounting Type
- Chassis Mount
- Features
- -
- Coil Insulation
- -
- Coil Type
- Non Latching
- Coil Resistance
- 7.6 kOhms
- Packaging
- Bulk
- Contact Material
- Silver Cadmium Oxide (AgCdO)
- Relay Type
- General Purpose
- Switching Voltage
- 115VAC, 28VDC - Max
- Part Status
- Active
- Termination Style
- Solder Hook
- Seal Rating
- Sealed - Hermetically
- Must Operate Voltage
- 65 VDC
