U7Y0269
AC DC Converters
- Manufacturer No:
- U7Y0269
- Manufacture:
- TDK-Lambda Americas Inc.
- Datasheet:
- U7Y0269
- Description:
- AC/DC CONVERTER 24V 400W
In Stock
5 pcs On sales
$474.52
Product Parameter
- Mounting Type
- Chassis Mount
- Current - Output (Max)
- 12.5A
- Power (Watts)
- 300W (400W Forced Air)
- Voltage - Input
- 85 ~ 264 VAC
- Size / Dimension
- 7.00" L x 3.94" W x 1.56" H (177.8mm x 100.0mm x 39.6mm)
- Number of Outputs
- 1
- Type
- Open Frame
- Voltage - Output 1
- 24V
- Series
- CFE400M (400W)
- Voltage - Output 2
- -
- Features
- Adjustable Output, Remote On/Off, Standby Output, Universal Input
- Voltage - Output 3
- -
- Approvals
- CE
- Voltage - Output 4
- -
- Efficiency
- 94%
- Voltage - Isolation
- 4kV
- Part Status
- Active
- Minimum Load Required
- -
- Applications
- ITE (Commercial), Medical
- Operating Temperature
- 0°C ~ 60°C (With Derating)
