MLZ1608A2R2MT000
Fixed Inductors
- Manufacturer No:
- MLZ1608A2R2MT000
- Manufacture:
- TDK Corporation
- Package:
- 0603 (1608 Metric)
- Datasheet:
- MLZ1608A2R2MT000
- Description:
- FIXED IND 2.2UH 500MA 250 MOHM
In Stock
0 pcs On sales
$0
Product Parameter
- Package / Case
- 0603 (1608 Metric)
- Material - Core
- Ferrite
- Type
- Multilayer
- Size / Dimension
- 0.063" L x 0.031" W (1.60mm x 0.80mm)
- Series
- MLZ
- DC Resistance (DCR)
- 250mOhm
- Ratings
- -
- Current - Saturation
- 130mA
- Q @ Freq
- -
- Current Rating (Amps)
- 500mA
- Packaging
- Digi-Reel®
- Height - Seated (Max)
- 0.037" (0.95mm)
- Shielding
- Shielded
- Operating Temperature
- -55°C ~ 125°C
- Tolerance
- ±20%
- Supplier Device Package
- 0603 (1608 Metric)
- Inductance
- 2.2µH
- Frequency - Self Resonant
- 80MHz
- Part Status
- Not For New Designs
- Inductance Frequency - Test
- 10MHz
- Mounting Type
- Surface Mount
