ME70202V1-000U-A99
DC Brushless Fans (BLDC)
- Manufacturer No:
- ME70202V1-000U-A99
- Manufacture:
- Sunon Fans
- Datasheet:
- ME70202V1-000U-A99
- Description:
- FAN 70X70X20MM 24VDC VAPO
In Stock
19 pcs On sales
$10.43
Product Parameter
- Bearing Type
- Vapo-Bearing™
- RPM
- 3200 RPM
- Power (Watts)
- 1.59W
- Noise
- 33.0 dB(A)
- Voltage Range
- 8 ~ 27.6VDC
- Width
- 20.00mm
- Static Pressure
- 0.140 in H2O (34.9 Pa)
- Series
- MagLev® ME
- Voltage - Rated
- 24VDC
- Weight
- 0.133 lb (60.33 g)
- Lifetime @ Temp.
- 70000 Hrs @ 40°C
- Air Flow
- 29.0 CFM (0.812m³/min)
- Material - Blade
- Polybutylene Terephthalate (PBT)
- Fan Type
- Tubeaxial
- Material - Frame
- Polybutylene Terephthalate (PBT)
- Features
- Auto Restart
- Size / Dimension
- Square - 70mm L x 70mm H
- Approvals
- CE, CUR, TUV, UL
- Ingress Protection
- -
- Part Status
- Active
- Current Rating (Amps)
- 0.066A
- Termination
- 2 Wire Leads
- Operating Temperature
- 14 ~ 158°F (-10 ~ 70°C)
