PPTC331LFBN-RC

Rectangular Connectors - Headers, Receptacles, Female Sockets

Manufacturer No:: PPTC331LFBN-RC
Manufacture:: Sullins Connector Solutions
Datasheet:: PPTC331LFBN-RC
Description:: CONN HDR 33POS 0.1 TIN PCB

In Stock

0 pcs On sales

$1.05

Product Parameter

Contact Type: Female Socket

Insulation Material: Polyester

Contact Finish Thickness - Mating: -

Contact Shape: Square

Number of Positions: 33

Mounting Type: Through Hole

Row Spacing - Mating: -

Connector Type: Header

Contact Finish - Post: Tin

Fastening Type: Push-Pull

Contact Length - Post: 0.126" (3.20mm)

Style: Board to Board

Number of Rows: 1

Current Rating (Amps): 3A

Series: -

Pitch - Mating: 0.100" (2.54mm)

Operating Temperature: -40°C ~ 105°C

Features: -

Voltage Rating: 250V

Mated Stacking Heights: -

Packaging: Tray

Contact Material: Phosphor Bronze

Contact Finish - Mating: Tin

Part Status: Active

Insulation Color: Black

Number of Positions Loaded: All

Termination: Solder

Insulation Height: 0.335" (8.51mm)

Material Flammability Rating: UL94 V-0

Applications: -

Ingress Protection: -

Contact Finish Thickness - Post: -
