MS05-2A87-78L
Reed Relays
- Manufacturer No:
- MS05-2A87-78L
- Manufacture:
- Standex-Meder Electronics
- Datasheet:
- MS05-2A87-78L
- Description:
- RELAY REED DPST 500MA 5V
In Stock
0 pcs On sales
$12.95
Product Parameter
- Seal Rating
- -
- Must Release Voltage
- 0.5 VDC
- Coil Current
- 13.4mA
- Operating Temperature
- -20°C ~ 70°C
- Coil Voltage
- 5VDC
- Contact Rating (Current)
- 500mA
- Contact Form
- DPST-NO (2 Form A)
- Operate Time
- 0.5ms
- Release Time
- 0.1ms
- Mounting Type
- Through Hole
- Series
- MS
- Coil Resistance
- 375 Ohms
- Features
- -
- Contact Material
- -
- Coil Type
- Non Latching
- Switching Voltage
- 200VAC, 200VDC - Max
- Packaging
- Tube
- Termination Style
- PC Pin
- Part Status
- Active
- Must Operate Voltage
- 3.75 VDC
