ROB-09238
Stepper Motors
- Manufacturer No:
- ROB-09238
- Manufacture:
- SparkFun Electronics
- Datasheet:
- ROB-09238
- Description:
- STEPPER MOTOR HYBRID BIPOLAR 12V
In Stock
436 pcs On sales
$16.85
Product Parameter
- Series
- -
- Diameter - Shaft
- 0.197" (5.00mm)
- Weight
- 0.441 lb (200.03 g)
- Size / Dimension
- Square - 1.665" x 1.665" (42.30mm x 42.30mm)
- Accuracy
- -
- Termination Style
- Wire Leads
- Features
- Round Shaft
- Steps per Revolution
- 200
- Approvals
- -
- Current Rating (Amps)
- 330mA
- Coil Type
- Bipolar
- Mounting Hole Spacing
- 1.220" (31.00mm)
- Step Angle
- 1.8°
- Operating Temperature
- -
- Part Status
- Active
- Length - Shaft and Bearing
- 0.945" (24.00mm)
- Rotor Inertia
- 18.7gcm²
- Torque - Holding (oz-in / mNm)
- 32.57 / 230
- Coil Resistance
- 32.6 Ohms
- NEMA Frame Size
- 17
- Type
- Hybrid
- Voltage - Rated
- 12VDC
