SCP30S5-DN
AC DC Converters
- Manufacturer No:
- SCP30S5-DN
- Manufacture:
- SolaHD
- Datasheet:
- SCP30S5-DN
- Description:
- 30W 5V SW PWR SPLY DIN
In Stock
4 pcs On sales
$156.59
Product Parameter
- Size / Dimension
- 2.55" L x 1.29" W x 4.71" H (65.0mm x 33.0mm x 120.0mm)
- Number of Outputs
- 1
- Type
- Enclosed
- Voltage - Output 1
- 5V
- Series
- SCP (30W)
- Voltage - Output 2
- -
- Features
- IP20, Universal Input
- Voltage - Output 3
- -
- Approvals
- CE, cURus
- Voltage - Output 4
- -
- Efficiency
- 70%
- Minimum Load Required
- No
- Part Status
- Active
- Operating Temperature
- -25°C ~ 65°C
- Applications
- ITE (Commercial)
- Current - Output (Max)
- 6A
- Mounting Type
- DIN Rail
- Power (Watts)
- 30W
- Voltage - Input
- 85 ~ 264 VAC, 100 ~ 375 VDC
