S1W0-2835408003-0000003S-00005
LED Lighting - White
- Manufacturer No:
- S1W0-2835408003-0000003S-00005
- Manufacture:
- Seoul Semiconductor Inc.
- Package:
- 1113 (2835 Metric)
- Datasheet:
- S1W0-2835408003-0000003S-00005
- Description:
- MID POWER 2835
In Stock
57701 pcs On sales
$0
Product Parameter
- Viewing Angle
- 120°
- Thermal Resistance of Package
- 30°C/W
- Current - Test
- 65mA
- Package / Case
- 1113 (2835 Metric)
- Base Part Number
- STW8A12D-S1
- Size / Dimension
- 0.130" L x 0.110" W (3.30mm x 2.80mm)
- Color
- White, Neutral
- Height - Seated (Max)
- 0.035" (0.90mm)
- Series
- 3528
- Supplier Device Package
- 3528
- CCT (K)
- 4000K 3-Step MacAdam Ellipse
- CRI (Color Rendering Index)
- 80
- Packaging
- Digi-Reel®
- Flux @ 25°C, Current - Test
- 31lm (Typ)
- Part Status
- Active
- Flux @ 85°C, Current - Test
- -
- Current - Max
- 180mA
- Lumens/Watt @ Current - Test
- 163 lm/W
- Mounting Type
- Surface Mount
- Voltage - Forward (Vf) (Typ)
- 2.95V
