2SA2223A

Transistors - Bipolar (BJT) - Single

Manufacturer No:: 2SA2223A
Manufacture:: Sanken
Package:: TO-3P-3 Full Pack
Datasheet:: 2SA2223A
Description:: TRANS PNP 260V 15A TO-3P

In Stock

1022 pcs On sales

$4.26

Product Parameter

Vce Saturation (Max) @ Ib, Ic: 500mV @ 500mA, 5A

Current - Collector (Ic) (Max): 15A

Series: -

Current - Collector Cutoff (Max): 10µA

Packaging: Bulk

DC Current Gain (hFE) (Min) @ Ic, Vce: 40 @ 5A, 4V

Part Status: Active

Voltage - Collector Emitter Breakdown (Max): 260V

Power - Max: 160W

Mounting Type: Through Hole

Package / Case: TO-3P-3 Full Pack

Transistor Type: PNP

Operating Temperature: 150°C (TJ)

Frequency - Transition: 35MHz

Supplier Device Package: TO-3P
