SCS7VT93HPL2VLS03F
LED Lighting - White
- Manufacturer No:
- SCS7VT93HPL2VLS03F
- Manufacture:
- Samsung Semiconductor, Inc.
- Package:
- 0505 (1313 Metric)
- Datasheet:
- SCS7VT93HPL2VLS03F
- Description:
- LED LM102A WARM WHT 3000K 2SMD
In Stock
27987 pcs On sales
$0
Product Parameter
- Mounting Type
- Surface Mount
- Thermal Resistance of Package
- 2°C/W
- Viewing Angle
- 145°
- Current - Test
- 150mA
- Package / Case
- 0505 (1313 Metric)
- Size / Dimension
- 0.053" L x 0.053" W (1.34mm x 1.34mm)
- Height - Seated (Max)
- 0.017" (0.42mm)
- Color
- White, Warm
- Supplier Device Package
- SMD
- Series
- LM102A
- CRI (Color Rendering Index)
- 70
- CCT (K)
- 3000K 5-Step MacAdam Ellipse
- Flux @ 25°C, Current - Test
- -
- Packaging
- Digi-Reel®
- Flux @ 85°C, Current - Test
- 111lm (103lm ~ 119lm)
- Part Status
- Active
- Lumens/Watt @ Current - Test
- 125 lm/W
- Current - Max
- 250mA
- Voltage - Forward (Vf) (Typ)
- 5.9V
