FAA1-08038NBMT31
AC Fans
- Manufacturer No:
- FAA1-08038NBMT31
- Manufacture:
- Qualtek
- Datasheet:
- FAA1-08038NBMT31
- Description:
- FAN AXIAL 80X38MM 115VAC TERM
In Stock
978 pcs On sales
$15.83
Product Parameter
- Series
- FAA1-08038
- Voltage - Rated
- 115VAC
- Weight
- 0.706 lb (320.24 g)
- Lifetime @ Temp.
- -
- Air Flow
- 24.0 CFM (0.672m³/min)
- Material - Blade
- Plastic
- Fan Type
- Tubeaxial
- Material - Frame
- Aluminum
- Features
- -
- Size / Dimension
- Square - 80mm L x 80mm H
- Approvals
- CE, cURus, TUV
- Ingress Protection
- -
- Part Status
- Active
- Current Rating (Amps)
- 0.060A
- Termination
- 2 Terminals
- Operating Temperature
- 14 ~ 158°F (-10 ~ 70°C)
- Bearing Type
- Ball
- RPM
- 2400 RPM
- Power (Watts)
- 4.00W
- Noise
- 26.2 dB(A)
- Voltage Range
- -
- Width
- 38.00mm
- Static Pressure
- 0.110 in H2O (27.4 Pa)
