AS03608MR-5-R
Speakers
- Manufacturer No:
- AS03608MR-5-R
- Manufacture:
- PUI Audio, Inc.
- Datasheet:
- AS03608MR-5-R
- Description:
- SPEAKER 8OHM 500MW TOP PORT 91DB
In Stock
1996 pcs On sales
$3.12
Product Parameter
- Impedance
- 8 Ohms
- Efficiency - Type
- Sound Pressure Level (SPL)
- Packaging
- Tray
- Material - Magnet
- N38
- Technology
- Magnetic
- Ingress Protection
- -
- Part Status
- Active
- Efficiency - Testing
- 100mW/100mm
- Power - Max
- 1W
- Height - Seated (Max)
- 0.181" (4.60mm)
- Termination
- Solder Pads
- Frequency - Self Resonant
- 500Hz
- Port Location
- Top
- Power - Rated
- 500mW
- Type
- General Purpose
- Frequency Range
- 500Hz ~ 4.5kHz
- Shape
- Round
- Material - Cone
- Polyester, Polyethylene Terephthalate (PET)
- Series
- AS
- Efficiency - dBA
- 91.00
- Ratings
- -
- Size / Dimension
- 1.417" Dia (36.00mm)
