90022-AS
Contacts, Spring Loaded and Pressure
- Manufacturer No:
- 90022-AS
- Manufacture:
- Preci-Dip
- Datasheet:
- 90022-AS
- Description:
- CONTACT SPRING LOADED SMD GOLD
In Stock
54368 pcs On sales
$0.6
Product Parameter
- Part Status
- Active
- Contact Finish Thickness
- 20.0µin (0.51µm)
- Contact Type
- Sleeve & Plunger
- Operating Force - Initial
- 25.49gf
- Plunger Size
- 0.042" (1.07mm) Dia
- Recommended Working Height
- -
- Mating Cycles
- 40000
- Material Flammability Rating
- -
- Mounting Type
- Surface Mount
- Operating Force - Mid Compression
- 61.18gf
- Contact Finish
- Gold
- Contact Material
- Brass Alloy
- Pad Layout Dimension
- Circular - 0.072" (1.83mm)
- Current Rating (Amps)
- 3A
- Series
- -
- Operating Temperature
- -55°C ~ 125°C
- Features
- -
- Maximum Working Height
- 0.167" (4.25mm)
- Packaging
- Bulk
- Minimum Working Height
- 0.112" (2.85mm)
