3031157
Terminal Blocks - Din Rail, Channel
- Manufacturer No:
- 3031157
- Manufacture:
- Phoenix Contact
- Datasheet:
- 3031157
- Description:
- CONN TERM BLK FEED THRU 14-26AWG
In Stock
1980 pcs On sales
$2.9
Product Parameter
- Color
- Gray
- Terminal - Width
- 4.2mm
- Series
- CLIPLINE STTB
- Termination Style
- Push In, Spring
- Features
- -
- Number of Positions
- 4
- Fuse Type
- -
- Material - Insulation
- Polyamide (PA), Nylon
- Part Status
- Active
- Wire Gauge or Range - AWG
- 14-26 AWG
- Current - UL
- 15A
- Wire Gauge or Range - mm²
- 0.08-1.5mm²
- Voltage - UL
- 300V
- Material Flammability Rating
- UL94 V-0
- Current - IEC
- 17.5A
- Voltage - IEC
- 500V
- Disconnect Type
- -
- Number of Levels
- 2
- Type
- Feed Through
- Stripping Length
- 10mm
