3005361
Terminal Blocks - Specialized
- Manufacturer No:
- 3005361
- Manufacture:
- Phoenix Contact
- Datasheet:
- 3005361
- Description:
- TERM BLK MIDDLE 4POS 16.2MM BLUE
In Stock
0 pcs On sales
$0
Product Parameter
- Height (Max)
- 0.866" (22.00mm)
- Operating Temperature
- -
- Voltage - UL
- 600V
- Wire Gauge or Range - AWG
- 14-26 AWG
- Current - IEC
- 17.5A
- Wire Gauge or Range - mm²
- 0.14-2.5mm²
- Housing Color
- Blue
- Material Flammability Rating
- UL94 V-0
- Mounting Type
- Direct Mount
- Voltage - IEC
- 800V
- Type
- Middle
- Number of Levels
- 1
- Length
- 1.260" (32.00mm)
- Stripping Length
- 9mm
- Series
- CLIPLINE MZDB
- Terminal - Width
- 16.2mm
- Features
- Engagement Pin
- Termination Style
- Push In, Spring
- Part Status
- Obsolete
- Number of Positions
- 4
- Current - UL
- 15A
- Material - Insulation
- Polyamide (PA), Nylon
