ODB19069-48HB10A
DC Brushless Fans (BLDC)
- Manufacturer No:
- ODB19069-48HB10A
- Manufacture:
- Orion Fans
- Datasheet:
- ODB19069-48HB10A
- Description:
- FAN IMP MTRZD 189.5X68.5MM 48VDC
In Stock
11 pcs On sales
$113.85
Product Parameter
- Features
- PWM Control, Speed Sensor (Tach)
- Size / Dimension
- Round - 189.5mm Dia
- Approvals
- CE, cURus, TUV, UR
- Ingress Protection
- -
- Part Status
- Active
- Current Rating (Amps)
- 2.55A
- Termination
- 4 Wire Leads
- Operating Temperature
- 14 ~ 149°F (-10 ~ 65°C)
- Bearing Type
- Ball
- RPM
- 3500 RPM
- Power (Watts)
- 122.0W
- Noise
- 77.0 dB
- Voltage Range
- 36 ~ 56VDC
- Width
- 68.50mm
- Static Pressure
- 2.810 in H2O (700.0 Pa)
- Series
- -
- Voltage - Rated
- 48VDC
- Weight
- 2.205 lb (1 kg)
- Lifetime @ Temp.
- 40000 Hrs @ 40°C
- Air Flow
- 432.0 CFM (12.10m³/min)
- Material - Blade
- Thermoplastic
- Fan Type
- Motorized Impellers
- Material - Frame
- Aluminum
