OD9225-SPOT/DIN
AC Fans
- Manufacturer No:
- OD9225-SPOT/DIN
- Manufacture:
- Orion Fans
- Datasheet:
- OD9225-SPOT/DIN
- Description:
- FAN AXIAL 120X32MM BALL 120VAC
In Stock
0 pcs On sales
$33
Product Parameter
- Bearing Type
- Ball
- RPM
- 1600 RPM
- Power (Watts)
- 19.00W
- Noise
- 20 ~ 47 dB
- Voltage Range
- -
- Width
- 32.00mm
- Static Pressure
- 0.430 in H2O (107.1 Pa)
- Series
- OD9225
- Voltage - Rated
- 120VAC
- Weight
- -
- Lifetime @ Temp.
- -
- Air Flow
- 65.0 CFM (1.82m³/min)
- Material - Blade
- Polybutylene Terephthalate (PBT)
- Fan Type
- Tubeaxial
- Material - Frame
- Polybutylene Terephthalate (PBT)
- Features
- Kit
- Size / Dimension
- Square - 120mm L x 120mm H
- Approvals
- cURus, TUV
- Ingress Protection
- -
- Part Status
- Active
- Current Rating (Amps)
- 0.600A
- Termination
- Cord and Plug
- Operating Temperature
- 14 ~ 158°F (-10 ~ 70°C)
