OA825AP-22-2WB
AC Fans
- Manufacturer No:
- OA825AP-22-2WB
- Manufacture:
- Orion Fans
- Datasheet:
- OA825AP-22-2WB
- Description:
- FAN AXIAL 80X27MM 230VAC WIRE
In Stock
0 pcs On sales
$15.84
Product Parameter
- Features
- -
- Size / Dimension
- Square - 80mm L x 80mm H
- Approvals
- cURus, TUV
- Ingress Protection
- -
- Part Status
- Active
- Current Rating (Amps)
- -
- Termination
- 2 Wire Leads
- Operating Temperature
- -4 ~ 176°F (-20 ~ 80°C)
- Bearing Type
- Ball
- RPM
- 2300 RPM
- Power (Watts)
- 6.00W
- Noise
- 18.0 dB
- Voltage Range
- 160 ~ 260VAC
- Width
- 27.00mm
- Static Pressure
- 0.140 in H2O (34.9 Pa)
- Series
- OA825
- Voltage - Rated
- 230VAC
- Weight
- -
- Lifetime @ Temp.
- 60000 Hrs @ 40°C
- Air Flow
- 18.0 CFM (0.504m³/min)
- Material - Blade
- Polybutylene Terephthalate (PBT)
- Fan Type
- Tubeaxial
- Material - Frame
- Aluminum
