OA225LFG221T
AC Fans
- Manufacturer No:
- OA225LFG221T
- Manufacture:
- Orion Fans
- Datasheet:
- OA225LFG221T
- Description:
- FAN AXIAL 320X141.5MM 230VAC
In Stock
0 pcs On sales
$175.13
Product Parameter
- Series
- OA225
- Voltage - Rated
- 230VAC
- Weight
- -
- Lifetime @ Temp.
- 40000 Hrs @ 40°C
- Air Flow
- 600.0 CFM (16.80m³/min)
- Material - Blade
- Metal
- Fan Type
- Tubeaxial
- Material - Frame
- Aluminum
- Features
- Kit
- Size / Dimension
- Square - 320mm L x 320mm H
- Approvals
- cURus, TUV
- Ingress Protection
- IP55 - Dust Protected, Water Resistant
- Part Status
- Active
- Current Rating (Amps)
- 0.350A
- Termination
- Terminal Block
- Operating Temperature
- -40 ~ 176°F (-40 ~ 80°C)
- Bearing Type
- Ball
- RPM
- 2800 RPM
- Power (Watts)
- 80.0W
- Noise
- 61.0 dB
- Voltage Range
- 200 ~ 240VAC
- Width
- 141.5mm
- Static Pressure
- 0.670 in H2O (166.9 Pa)
