OA205AN-22-1WB1856
AC Fans
- Manufacturer No:
- OA205AN-22-1WB1856
- Manufacture:
- Orion Fans
- Datasheet:
- OA205AN-22-1WB1856
- Description:
- FAN AXIAL 205X72MM 230VAC WIRE
In Stock
1 pcs On sales
$96.38
Product Parameter
- Air Flow
- 650.0 CFM (18.20m³/min)
- Material - Blade
- Metal
- Fan Type
- Tubeaxial
- Material - Frame
- Aluminum
- Features
- -
- Size / Dimension
- Square - 205mm L x 205mm H
- Approvals
- cURus, TUV
- Ingress Protection
- IP56 - Dust Protected, Water Resistant
- Part Status
- Active
- Current Rating (Amps)
- -
- Termination
- 2 Wire Leads
- Operating Temperature
- -22 ~ 176°F (-30 ~ 80°C)
- Bearing Type
- Ball
- RPM
- 3200 RPM
- Power (Watts)
- 105W
- Noise
- 68.0 dB(A)
- Voltage Range
- 200 ~ 240VAC
- Width
- 72.00mm
- Static Pressure
- 1.080 in H2O (269.0 Pa)
- Series
- OA205AN
- Voltage - Rated
- 230VAC
- Weight
- 5.1 lbs (2.3 kg)
- Lifetime @ Temp.
- 50000 Hrs @ 55°C
