ED655/2DS
Terminal Blocks - Wire to Board
- Manufacturer No:
- ED655/2DS
- Manufacture:
- On-Shore Technology, Inc.
- Datasheet:
- ED655/2DS
- Description:
- TERM BLK 2POS SIDE ENTRY 7MM PCB
In Stock
1202 pcs On sales
$1.16
Product Parameter
- Current
- 6A
- Dielectric Material
- Polyamide (PA), Nylon
- Voltage
- 250V
- Positions Per Level
- 2
- Features
- -
- Operating Temperature
- -30°C ~ 105°C
- Packaging
- Bulk
- Clamp Material - Plating
- Copper Tin Alloy
- Wire Gauge
- 16-28 AWG
- Screw Material - Plating
- -
- Part Status
- Active
- Contact Material - Plating
- Brass
- Screw Thread
- M2
- Mounting Type
- Through Hole
- Torque - Screw
- 0.4 Nm (3.5 Lb-In)
- Color
- Gray
- Number of Levels
- 1
- Pitch
- 0.276" (7.00mm)
- Wire Termination
- Screw
- Series
- ED655/DS
- Mating Orientation
- Horizontal with Board
