6N137SDM
Optoisolators - Logic Output
- Manufacturer No:
- 6N137SDM
- Manufacture:
- ON Semiconductor
- Package:
- 8-SMD, Gull Wing
- Datasheet:
- 6N137SDM
- Description:
- OPTOISO 5KV 1CH OPEN COLL 8SMD
In Stock
57859 pcs On sales
$0
Product Parameter
- Number of Channels
- 1
- Voltage - Isolation
- 5000Vrms
- Operating Temperature
- -40°C ~ 100°C
- Series
- -
- Inputs - Side 1/Side 2
- 1/0
- Data Rate
- 10Mbps
- Rise / Fall Time (Typ)
- 30ns, 10ns
- Packaging
- Digi-Reel®
- Supplier Device Package
- 8-SMD
- Input Type
- DC
- Current - Output / Channel
- 50mA
- Output Type
- Open Collector
- Voltage - Forward (Vf) (Typ)
- 1.45V
- Part Status
- Active
- Current - DC Forward (If) (Max)
- 50mA
- Mounting Type
- Surface Mount
- Propagation Delay tpLH / tpHL (Max)
- 75ns, 75ns
- Package / Case
- 8-SMD, Gull Wing
- Common Mode Transient Immunity (Min)
- 10kV/µs (Typ)
- Voltage - Supply
- 4.5V ~ 5.5V
